TDA8954TH DIGITAL AUDIO AMPLIFIER BOARD 420W*2 HIGH POWER

This product uses the new original TDA8954TH chip. Compatible with the characteristics of Class A and Class D amplifiers.

Both the mellow sound quality of the analog amplifier and the high efficiency of the digital amplifier. Each mono using BTL mode output power can reach 420W. Graphics card cooling fan to ensure heat dissipation.

parameter:

Name: Digital Audio Amplifier

Model:XH-M254

Chip Model: TDA8954TH

Input voltage: AC20-28V

Input current: 5A or more

Input impedance: 1Kohm

Channel: 2 channels

Magnification: 33 times

Output power: 420W*2

Output Impedance: 4-8ohm

Type: AD class

Size: 142*106*25mm

Weight: 460g
